生成物声明函　　配伍规模性　　该机合适于各种超超大板料的分割，如30g/m2-300g/m2头层牛皮纸厂家生产的牛皮纸、白打印机卡纸、淋膜纸、铝铂、PVC塑料管、经编织袋、锡纸等板料的分割、复卷等。　　可以及特性　　1. 该机型进行异步伺服控制器机械(失量机械)放肆、积极主动锥度涨力，后面卷取体例。监控主机进行直流变频空调变速，始终坚持更快如表衡启用。　　2. 拒绝计米、报警功能效果。收卷去接纳A、B气胀轴布置，卸装调控便利性。　　3. 放卷尊重光电公司分手后纠偏纠错指标体系，使不规则資料能通常情况分切机。　　4. 圆刀纵切废边主动的排放口配备。5. 油压机式会去主动装料，配气胀轴。6.导轨式相互下料机安装。也可单向拉开卸料！product manualScope of applicationThis machine is suitable for the slitting of various super-large coils, such as slitting and rewinding of 30g/m2-300g/m2 kraft paper, white cardboard, coated paper, aluminum foil, PVC plastic, Woven bag, tin foil and other coils.Performance and characteristics1. The machine adopts asynchronous servo motor (vector motor) control, automatic taper tension and center winding method. The main engine adopts frequency conversion speed regulation to maintain balanced operation during acceleration.2. Automatic metering and alarm function. The winding adopts the A and B air expansion shaft structure, and the unloading operation is convenient.3. Unwinding adopts photoelectric automatic correction correction system to make irregular materials cut normally.4. The circular knife cuts the waste side automatic discharge device.5. Hydraulic automatic feeding, with air expansion shaft.6. Rail type automatic cutting device. The unloading can also be opened unilaterally! 　　基本手工艺技术参数：Main Technical Parameters

型号 Model	CLFQ-W800	CLFQ-W1300
zui大材料高度MAX. Width of raw material	800mm	1300mm
zui大放卷网套直径Max.parent Web Diameter	Φ1400mm	Φ1400mm
zui大收卷网套直径Max.Rewinding Diameter	Φ1100mm	Φ1100mm
zui高机器人传输速率 Max.Machine Speed	10-400m/min	10-400m/min
总工率 Total Power	22KW	25KW
食用量 Machine Weight	4000kg	4800kg
形状图片规格 Overall Dimensions	2500×2900×2000mm	3000×2900×2000mm
zui小分切机宽 Min.Slitting Width	50mm

可依照规定生成物标准 格外订造准备。Can be made according to the product requires special equipment. 增长到关头词：编织而成袋内阀膜分割机，阀口袋吧膜分割机
