匠人参数设置Parameters

机型 Model	QFJ-700	QFJ-1100	QFJ-1300
卷材宽度 MAX.Parent Web Width	700mm	1100mm	1300mm
放卷直径 Max.parent Web Diameter	Φ600mm	Φ600mm	Φ600mm
收卷直径 Max.Rewinding Diameter	Φ400mm	Φ400mm	Φ400mm
分切速率 Max.Machine Speed	10-180m/min	10-180m/min	10-180m/min
总功率 Total Power	4KW	4KW	5.5KW
分量 Machine Weight	1700kg	1900kg	2100kg
形状尺寸 Overall Dimensions	1200×1900×1270	1200×2300×1370	1200×2500×1370
分切宽度 Min.Slitting Width	圆刀Round Blade：30mm	直刀Razor Blade :20mm

可依据物品重定向 个人定制裝备。

꧅Can be made according to the product requires special equipment.

用途： 此机混用于BOPP、PET、PE、PVC、铝泊、纸型、以及圈筒状资源的细分。

杭州特色：1、该机专属于卧式分条机。2、自力微机控制屏，控制连锁便利店。3、收、放卷拉伸应变磁粉吃妻上瘾。4、走料及时计米，放卷光电产品及时纠偏。5、包括边垃圾风送或卷取装配线。6、双气胀轴收卷，分切机端口陡峭。7、铝泊、纸张类型模切须挑选那些圆刀配件。

USES:

🌳This machine is suitable for BOPP, PET, PE, PVC, aluminum foil, paper, the classification of the drum all material.

Features:

ᩚᩚᩚᩚᩚᩚ⁤⁤⁤⁤ᩚ⁤⁤⁤⁤ᩚ⁤⁤⁤⁤ᩚ𒀱ᩚᩚᩚ1, the machine belong to vertical slitting machine.

🀅2, independent microcomputer control panel, easy to operate.

3, closed, tension magnetic powder control.

൩4, go automatic meter, rolling photoelectric automatic adjustment.

5, the edge waste wind send or coiling device.

ꦰ6, double winding, gassing axis cutting face is flat and level.

ও7, aluminum foil, paper cutting and must choose and circular knife accessaries.
